50000 Liters Diesel Tanker Trailer

Name: 50000 Liters Diesel Tanker Trailer
Rating: 0.00 (0 reviews)

TITAN is diesel tanker trailer for sale manufacturer from China. We supply 4 axle 50000 liters diesel tank truck trailers for sale. We can customize. Including 2/3/4 Axles, 35000/40000/42000/45000/50000 Liters. TITAN can also provides all kinds of different diesel tanker trailer for sale according to customers 's need.

SKU:

GTIN:

MPN:

Brand:

Diesel Tanker Trailer Description:

50000 liters diesel tanker trailer for sale as they are commonly called are vehicles with large tanks for transporting liquids. They are designed for specific safe shipping of various liquids. Diesel tanker trailer for sale can be equipped with a pumping system for loading and off-loading liquids.

This diesel tanker price could use typically two, three, four, five, and sometimes six compartments and are capable of transporting a variety of liquids, including fuels such as different gasoline grades, diesel, and industrial chemicals.

Diesel Tanker Trailer for Sale | 50000 Liters Diesel Tanker Price

Diesel Tanker Price Specification：

Dimension: 11500mm * 2500mm *3700mm

Total volume(L): 50000 L

Tank Body Material: Q235 carbon steel

End plate: Q235 carbon steel

Manhole Cover: Carton steel

Bottom Valve: Aluminum API Pneumatic Bottom Valve

Compressor: BOHAI 10m³/12m³ or other brands

Discharging Valve: Diameter is 3 or 4 inch

Compartments: 5 Compartment

Discharging Pipe: 4 inch rubber hose,2pcs,6m/each

Cat Walk: With (common model or special design)

Main beams: Welded design or special design I beam, connected by bolts and nuts Q345 carbon steel material

Axle: 4 axles,13T,FUWA

Landing Gear: JOST(D200T) or China brand 28T

Kingpin: JOST 2.0 or 3.5 inch bolt-in king pin

Diesel Tanker Price Suspension: Ari Suspension

Leaf Spring: 90(w)mmx13(thickness)x10layers or 10mm x12mmx12 layers

Pneumatic Braking System: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tank

Rim: 9.00-22.5Chinese brand

Tire: 12.00R22.5

ABS: Optional

Diesel Tanker Price Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layer of top coats.

Accessories: One standard tool box

Shipping Terms: By bulk cargo, RORO or 40HQ containers

Diesel Tanker Advantage:

1.We use high strength steel to make diesel fuel trailer for sale, which makes the tank body very strength.

2.TITAN use the most advanced single-sided welding and double-sided forming welding technology, which make the welding seam is stronger and smoother and there will never be a phenomenon of open welding.

3.The tank body adopts longitudinal welding technology, which reduces the number of welding seams of the tank body and improves the overall firmness of the tank body by more than 20%.

4.TITAN's diesel tanker trailer is equipped with anti-wave board, which can greatly reduce the impact of the liquid inside on the trailer during transportation and greatly improve the safety of the trailer.

5. Our diesel tanker trailer for sale uses polyurethane paint that costs twice as much as ordinary paint, which is not only beautiful in color, but also has strong adhesion and will not fall off even after 5 years of use.

Through this video, you can learn about different types of fuel tanker trailers, as well as the process, testing, packaging and customer feedback, etc.
